| Type of refrigerant |
R134a or HFO1234yf |
| Service procedure |
Fully automatic or manual |
| Voltage |
220-240V 50/60 Hz |
| Scale resolution |
10 g |
| Oil scale resolution |
5 g |
| Working temperature range |
11/49°C |
| Filter system |
1 filter for humidity (112gr) |
| Vacuum pump |
100 litre/min capacity, 0.1 mbar vacuvum level |
| Sealed compressor |
1/3 HP (SPECIAL COMPRESSOR FOR 4000-ME) |
| Recovery speed |
300 g/min in liquid phase |
| Refrigerant tank |
22 litres, refillable (12 litres for HFO) |
| Hoses |
3 metres |
| Overall size |
55 x 60 x 110 cm |
| Weight |
90 kg |
| Thermal printer |
Standard |
| Pressure gauges |
Class 1 |
| Display |
Graphic color touch screen |
| Bottle temperature sensor |
Integrated |
| Bottle heater | Automatic |
 |
 |
 |
| Large 7” Color Display with touch-screen icon messaging for easy use. | 3 Hermetic & refillable containers for new oils (PAG,POE) and for dye. | USB port for software update and Wi-Fi/LAN ready |
 |
||
| Nitro Integrated Nitrogen and Nitrogen+Hydrogen leak detection with a connection for external tank | Hybrid (patent pending) Flushing of station and service hoses for use with vehicles equipped with electric compressors. | |
 |
 |
| Gas Identifier controlled by the machine. |
Diag (only for R134a) Dynamic diagnosis module. |
