| Automatic Leak Testing The station checks for leaks during the vacuum phase. If leaks are found, it interrupts operation and gives an alarm. |
| Automatic Discharge (PATENT PENDING) of non-condensable gases via solenoid valves, with tank temperature and pressure sensors. |
 Gear Pump |
| Type of refrigerant |
R134a |
| Service procedure |
Fully automatic or manual |
| Voltage |
220-240V - 50/60 Hz |
| Scale resolution |
10 g |
| Oil scale resolution |
5 g |
| Working temperature range |
11/49°C |
| Filter system |
2 filters for humidity |
| Vacuum pump |
170 litre/min capacity, 0.1 mbar vacuum level |
| Compressor |
Hermetically sealed, 21 cc, high pressure |
| Gear pump |
1 kg/min capacity |
| Refrigerant tank |
40 litres, refillable |
| Hoses |
6 metres |
| Overall size |
80 x 120 x 115 cm |
| Weight |
140 kg |
| Thermal printer |
Standard equipment |
| Display |
LCD |
| Pressure gauges | Class 1 |
